ABS MOULDING-BASF-Terluran GP-35

Add to compare
Sold by
@ Plastic Dealer

Report Abuse

Product description

Easy-flow injection moulding product with good ductility, intended for mouldings with thin walls and/or adverse flow length to wall ratio.

Physical form and storage

Terluran® is delivered as spherical pellets. The bulk density of the pellets is from 0.55 to 0.65 g/cm³. Standard Packaging unit: 25 kg PE-bag on palette, shrunk or wrapped with PE film or delivery in silo trucks. PE bags should not be stored outside.

In dry areas with normal temperature control, Terluran® pellets can be stored for relatively long periods of time without any change in mechanical properties. Under poor storage conditions, Terluran® absorbs moisture, but this can be removed by drying.

Properties
Polymer abbreviation ABS
Density ISO 1183 kg/m³ 1040
Water absorption, equilibrium in water at 23°C similar to ISO 62 % 0.95
Moisture absorption, equilibrium 23°C/50% r.h. similar to ISO 62 % 0.24
Processing
Processing: Injection moulding (M), Extrusion (E), Blow moulding (B) M
Melt volume-flow rate MVR 220 °C/10 kg ISO 1133 cm³/10min 34
Pre-drying: Temperature °C 80
Pre-drying: Time h 2 – 4
Melt temperature, injection moulding °C 220 – 260
Mould temperature, injection moulding °C 30 – 60
Moulding shrinkage, free, longitudinal % 0.4 – 0.7
Flammabillity
UL94 rating at 1.6 mm thickness UL-94 class HB
Automotive materials (thickness d >= 1mm) +
Mechanical Properties
Tensile modulus ISO 527-1/-2 MPa 2300
Yield stress, 50 mm/min ISO 527-1/-2 MPa 44
Yield strain, 50 mm/min ISO 527-1/-2 % 2.4
Nominal strain at break, 50 mm/min ISO 527-1/-2 % 12
Flexural strength ISO 178 MPa 65
Charpy impact strength (23°C) ISO 179/1eU kJ/m² 125
Charpy impact strength (-30°C) ISO 179/1eU kJ/m² 90
Izod notched impact strength (23°C) ISO 180/A kJ/m² 22
Izod notched impact strength (-30°C) ISO 180/A kJ/m² 7
Charpy notched impact strength (23°C) ISO 179/1eA kJ/m² 19
Charpy notched impact strength (-30°C) ISO 179/1eA kJ/m² 7
Izod notched impact strength, method A (23°C) ASTM D 256 J/m 240
Ball indentation hardness at 358 N/30 s ISO 2039-1 MPa 99
Thermal properties
HDT A (1.80 MPa) ISO 75-1/-2 °C 78
HDT B (0.45 MPa) ISO 75-1/-2 °C 89
Vicat softening temperature VST/A/50 ISO 306 °C 102
Vicat softening temperature VST/B/50 ISO 306 °C 95
Max. service temperature (short cycle operation) °C 80
Coefficient of linear thermal expansion, longitudinal (23-80)°C ISO 11359-1/-2 E-4/°C 0.8 – 1.1
Thermal conductivity DIN 52612-1 W/(m K) 0.17
Electrical properties
Volume resistivity IEC 60093 Ohm*m 1E13
Electric strength K20/P50, d = 0.6 – 0.8 mm IEC 60243-1 kV/mm 38

Specification: ABS MOULDING-BASF-Terluran GP-35

ALPHA

B

Group

ABS

Class

ABS MOULDING

DENSITY

1.04

GRADE

Terluran GP-35

NOTES

ABS

PROCESS

MOULDING

Special Properties

Terluran? GP-35 is high-flow, general purpose injection molding grade with good ductility, intended for moldings with thin walls and/or adverse flow length to wall ratio.

Typical Applications

Injection molding Thin wall components for telecommunications Household and sanitary appliances Toys Automotive components

Country

German

Tds-Name

0900766b813c901f.pdf

Tds-Url

https://docs.rs-online.com/301d/0900766b813c901f.pdf

D-Type

X

Brand

B>BASF
