Product Description
“Moplen” HP500N is a homopolymer suitable for injection moulding applications. It exhibits a good fluidity combined with a high stiffness.”Moplen” HP500N is extensively used in many injection moulding applications, such as furniture, crates, closures and containers.
| Physical
Density |
Nominal Values
0.900 |
(SI)
g/cm³ |
Test Method
ISO 1183 |
| Melt Mass-Flow Rate (MFR) (230°C/2.16 kg) | 12 | g/10 min | ISO 1133 |
| Melt Volume-Flow Rate (MVR) (230°C/2.16 kg) | 16.0 | cm³/10min | ISO 1133 |
| Mechanical
Tensile Modulus |
Nominal Values
1550 |
(SI)
MPa |
Test Method
ISO 527-1, -2 |
| Tensile Stress at Yield | 35.0 | MPa | ISO 527-1, -2 |
| Tensile Strain at Yield | 10 | % | ISO 527-1, -2 |
| Tensile Strain at Break | 50 | % | ISO 527-1, -2 |
| Impact | Nominal Values (SI) | Test Method | |
| Charpy Unnotched Impact Strength
(0 °C, Type 1, Edgewise) |
30.0 kJ/m² |
ISO 179 | |
| (23 °C, Type 1, Edgewise) | 110 kJ/m² | ||
| Charpy Notched Impact Strength (23 °C, Type 1,
Edgewise, Notch A) |
3.00 | kJ/m² | ISO 179 |
| Hardness | Nominal Values (SI) | Test Method | |
| Ball Indentation Hardness (H 358/30) | 70.0 MPa | ISO 2039-1 | |
| Thermal | Nominal Values (SI) | Test Method | |
| HDT (0.45 MPa) Unannealed | 80.0 °C | ISO 75-1, -2 | |
| Vicat Softening Temperature | ISO 306 | ||
Specification: PP MOULDING-CHINA-H500N
|
